T Slot Cutter Nz Rating: 3,9/5 2997 votes
T Slot Cutter Nz

This International Standard specifies the dimensions of T-slot cutters with plain or flatted cylindrical shanks, withthreaded shanks and with Morse taper shanks having tapped hole.It applies to those tools which are intended for manufacturing T-slots for machine tools for equipment, inaccordance with ISO 299.T-slot cutters with plain cylindrical shanks or flatted. Just a quick video, how I cut down Slotcar axles to reduce their length. I use my Tire Razor tyre machine and a dremel with a cut of wheel. Makes a neat job everytime! See more info online at http. T-SLOT CUTTERS – IMPERIAL (W x D) Add to Wishlist 5/16′ x 45/64′ HSS ‘T’ – Slot Cutter – Thrded Shk – Clarkson. All prices are listed in New.

Groove Milling by Circular Interpolation, Thread Milling, T-slot Milling, Solid Carbide Endmills

System DC

Solid carbide end mills DC:

  • Thread milling part profile from M1,6
  • Thread milling full profile on M3
  • Groove milling from 4 mm diameter
  • Chamfer milling from 2 mm diameter

Solid carbide end mills DCX:

  • Cutting edge max. = 40 mm
  • Cutting width 1.5 mm - 3 mm
  • Milling depth tmax = 15 mm

Groove Milling by Circular Interpolation M306-M335

Tool system with 3 and 6 cutter circular interpolation inserts for

  • Groove milling
  • Full radius milling
  • Chamfers
  • Bore, thread and face milling
  • Cuttingedge diameter from9.6 mm
  • Cuttingwidth up to10mm
  • Cutting depthtmax= 12mm

Disc Milling Cutter Type M101

Disc milling cutter forslotmilling

  • Slotmillingfrom63 mm diameter
  • Cuttingwidthsfrom 1.6 to 4.0mm
  • Cutting edge diameter80 mm -200mm
  • Cutting depthtmax= 59mm

Groove Milling by Circular Interpolation M275

T slot cutter nz price

Tool systemwith 2-edgedscrewedmilling insertsM275

  • Fromcuttingdiameter31 mm
  • Cutting depthtmax= 2.5mm

Available types:

  • End mills
  • Screw-in cutter
  • Shell end mills
  • Disk milling cutter

Groove Milling by Circular Interpolation 380/381

Cutter headsandside milling cutterswithscrewedinsertstype314

  • From bore diameter44 mm
  • Cutting widthup to5.26mm
  • Cutting depth tmax=5 mm

Available types:

  • End mills
  • Shell end mills
  • Side milling cutter

Side Milling Cutters M382 / M383

Disccutters withindexable insertstype314 screwed on both sides for:

  • Groove milling
  • Slot milling
  • Cuttingwidth6mm-14 mm
  • Cutting diameter80 mm -200mm

Side Milling Cutter M310

Disccutters withindexable insertstypeS310 screwed on both sides for:

  • Groove milling
  • Slot milling
  • Cuttingwidth 3mm-5mm
  • Cutting diameter80 mm -200mm

Thread Milling

Thread milling by circular interpolationwith cutterM306,M308, M311, M313, M328, M275andM380.

Milling tools for manufacturing of:

  • Metric ISO threads
  • Whitworth pipe threads

Gear Milling

Tool systems formodule0.5 tomodule 6(pressure angle of 20°)

  • Gear milling
    • Cylindrical gears
    • Shaft-hub connections
    • Worm shafts
    • customized gearprofiles

T-slot Milling

MillingM311,M313andM328for the manufacturing ofT-slots:

  • Slot widths:
    • 17 mm
    • 20mm
    • 24 mm

Polygon Milling

Tool system for producing polygon profiles on lathes, for grooving or longitudinal milling.

Solutions for various lathes with driven tooling.

Polygon milling insert types:

  • 314
  • S274

Thread Whirling

T slot cutter speeds and feeds

Tool system M302for making specialthreads onlathes.
Standard and customsolutions for whirling heads, suitable for all commoninterfaces.

Milling System DG

End millswith interchangeableheads for:

  • Centre cutting and groove milling
  • Chamfering and centering
  • Copy milling
  • Highfeedmilling

Availablein diameters:

  • 10mm
  • 12mm
  • 16 mm
  • 20mm

DA / DAH Milling System

End mill, screw-in mill and shell end mill type DAM for the following applications:

  • Face milling
  • Pocket milling
  • Plunge milling
  • Expanding
  • Shoulder milling
  • Chamfering

T Slot Cutter Nz Sale

Positive inserts geometry for easy cutting.

End mill, screw-in mill and shell end mill type DAHM for the following applications:

  • High feed milling
  • 2- or 3-edged milling inserts

Tangential Milling System M406

90°cutter shankfor cuttingaccurate90° shoulders

  • CuttingdiameterDs16 mm - 40mm
  • Cutting depthapmax=6.3 mm

Tangential Milling System M409

Tangential milling cutters in the following designs:

  • 90 ° cutter shank and blade head for milling exact 90 ° shoulders
  • 45 ° and 60 ° cutter head
  • Porcupine cutter
  • Side milling cutter
  • Cutting diameter from 32 mm to 125 mm
  • Cutting depth apmax = 9.3 mm

Solid Carbide Endmills DP / DS

End mills DP:

T Slot Cutter Nz Price

Full radius, torus, roughing and double radius cutter. Suitable for:

  • General steels

Cutting circle diameter of 3 mm to 20 mm

End Mills DS:

Full radius, torus, micro, roughing and double radius cutter. Suitable for:

  • General steels
  • High-strength steels
  • Hardened steels
  • Cobalt-chromium steels
  • Graphite
  • Aluminum

Cutting circle diameter of 0.1 mm to 20 mm

T Slot Cutter Speeds And Feeds

System URMA

Modular tooling system for spot facing with URMA Intramax:

  • Diameter range: 49 mm - 207 mm
  • For cutting boards type 105/110
  • For indexable inserts type 315

T Slot Cutter Mill

Modular tooling system for finishing bores with URMA fine head:

  • From a diameter of 0.2 mm
  • Fine boring head set exactly
Slot

T Slot Cutter Nz For Sale

Inserts available for use with:

T Slot Cutter Router Bit

  • Steel
  • Cast
  • Hardened steel
  • Aluminum alloys
